Mains Fed Water Cooler

A water Cooler designed and built to provide infection prevention and water safety with healthcare facilities in mind. Built with anti-bacterial stainless-steel body, providing water at between 8-10 degrees at 35 - 40 litres per hour.

Key Features:

• Main fed water cooler with in-line 10-micron filter that can be change based on individual requirements.
• All components help to prevent growing of water micro-organisms and all components WRAS approved.
• Internal copper pipework throughout.
• Anti-bacterial dispense button located at the top of unit at an accessible height, to enable easy access for all users including those in wheelchairs or with restricted mobility. A foot operated unit is also available upon request.
• Replaceable anti-bacterial dispense button
• All drips from the nozzle are channelled directly into the waste outlet to prevent water standing in a drip tray

Specification:

External Fabric

• 316 Stainless Steel Body with sloping top
• In-line 10-mircon filter can be installed onto mains pipework going into water dispenser.

Internal Fabric

• Internal funnel and drip outlet cover, ½” bulkhead copper feed to 8mm internal copper pipework throughout
• No plastic pipework
• Local isolation valve
• Internal double check valve
• Outlet can only accommodate 7 oz cup preventing water bottles from being used to stop cross contamination
• Easy to maintain and service with service contracts available upon request

Dimensions

• Floor standing unit is 1200mm h x 340mm w x 380mm d, however worktop mounted cooler or bespoke sizing available upon request

Electrical requirements

• 230V supply with kettle lead fitting
• Heat resistant plastic around electrical circuit areas

Dispensing button

• Antibacterial nozzle that can be replaced every month
• Foot pedal option also available

Water Temperature

• Mains fed water consistently providing between 8-10 degrees dispensing water at 35-40 litres per hour

Waste Outlet

• 1 ¼” plastic waste trap with P trap

Cup holder

• 7 oz stainless steel cup holder can be provided on the side of unit upon request for additional cost.

Download the Water Cooler specification as a PDF here.
